VET-007 focuses on high-precision fields such as aerospace and satellites, simulating the extreme environment of space: 1×10⁻⁵Pa extreme vacuum + -180~200℃ wide temperature range, integrated solar radiation + infrared heating functions, providing a precise testing environment for product reliability verification.
Öğe Hayır. :
VET-007Minimum Sipariş Miktarı (MOQ) :
1 SetÖdeme yöntemi :
L/C, T/TFiyat :
NegotiableÜrün oranı :
CHINATedarik Yeteneği :
10 Set per monthKurşun zamanı :
90 DaysGeleneksel ambalaj :
PlywoodSpace Grade Thermal Vacuum Test System 1×10⁻⁵Pa Extreme Vacuum -180~200℃ Wide Temperature Range
Core features
Testing capabilities
| Parameter | Technical Details |
| Model | VET-007 |
| Ultimate Vacuum | Better than 1×10⁻⁵ Pa |
| Working Vacuum | Better than 1.3×10⁻⁴ Pa |
| Temperature Range | -180℃ ~ 200℃ |
| Temperature Control Precision | ±0.5℃ |
| Temperature Uniformity of Radiator | ≤ ±5℃ |
| Radiator Surface Properties | Inner wall painted black; Solar absorptivity ≥0.95; Hemispherical emissivity ≥0.90; No radiation shielding on outer surface |
| Infrared Heating Heat Flux | 100W/m² ~ 1800W/m² |
| Measurement Capabilities | Vacuum & temperature measurement |
| Chamber Material | AISI 304L stainless steel (seamless welding) |
| Chamber Door Design | External sandblasting + internal cooling fins; Equipped with wheel locks & fluororubber O-rings |
| Vacuum System Configuration |
Internationally renowned brand (two-stage vane pump + helium cryopump with exhaust filter) |
| Power Supply | 3φ 220V/380V/480V+N+G, 50/60Hz |
